ABLOY PRODUCT
CLIQ Flush Mounted Indoor Reader TQ311T
TQ311T
CLIQ Flush Mounted Indoor Reader TQ311T
TQ311T verifies an inserted CLIQ key and switches a potential-free contact when authorized, for electric strikes, motorized locks, automatic doors and switching applications.
- Brand
- ABLOY
- Model
- TQ311T
- Type of product
- Accessory
- Platform
- PROTEC2 CLIQ
- Cylinder type
- Single
- Cylinder shape
- Finnish
Product features
- Offline connection; rights are programmed through CLIQ Web Manager or CLIQ Local Manager.
- Dimensions: 71 × 71 × 45 mm; minimum flush-box depth: 60 mm; box not included.
- Free output rated 1 A at 12 V AC or 24 V DC; switching time about 1–10 seconds, optionally triggered on key insertion or removal.
- Device supply: 12–24 V DC ±10%; 0.1 A at 12 V, supply not included; operating temperature: −25°C to +60°C.
- Optional separate remote-relay security unit at up to 2 m; indoor use only.
Before ordering
Provide the complete model of the main product and installation photographs, and check fixings, interfaces and quantities. This is an accessory, not a complete set that necessarily includes the main lock or control device.
Other products in this category
Compare the listed fields; these links do not imply interchangeability.
Request product documents
For data sheets, installation instructions or drawings, contact CLTECH with the model and required configuration.
Contact CLTECH for documents
