ABLOY PRODUCT
ASSA ABLOY Access Controller AMX1100
AMX1100
ASSA ABLOY Access Controller AMX1100
AMX1100 connects to ASSA ABLOY Access over a network using static IP or DHCP, supports two readers, and enables access-right and data updates on keys and credentials.
- Brand
- ABLOY
- Model
- AMX1100
- Type of product
- Access and security control system component
Product features
- Dimensions: 164 × 140 × 26 mm; weight: 352 g.
- Supply: 12–24 V DC; the source specifies 1.9 A excluding external loads.
- The real-time clock is backed by a 3 V CR2032 lithium battery and continues during power outages.
- One 10/100 Mb Ethernet interface and one Micro-USB interface (5 V / 500 mA).
- Operating temperature: 0°C to +70°C; relative humidity: 5–85%, non-condensing.
Before ordering
Identify the product’s role in the PULSE system, then check its mounting interface, keys and management arrangement. Do not substitute mechanical cylinders or CLIQ products based on appearance.
Other products in this category
Compare the listed fields; these links do not imply interchangeability.
Request product documents
For data sheets, installation instructions or drawings, contact CLTECH with the model and required configuration.
Contact CLTECH for documents
