ABLOY PRODUCT
Door closer DC200
DC200
Door closer DC200
DC200 is a rack-and-pinion closer with an L190 link arm or L191 hold-open link arm for single-action doors up to 1100 mm wide.
- Brand
- ABLOY
- Model
- DC200
- Force adjustment
- Yes
- Height adjustable spindle
- Yes
- Operating temperature
- -30 to +50°C
- Mounting position
- Hinge side, door leaf mounting, Non-hinge side, frame mounting
- Max closing force
- EN4
- Max opening angle non-hinge side
- 180°
- Min closing force
- EN2
- Installation type
- Overhead
- Max opening angle hinge side
- 180°
- Hold open function
- No
- Type of product
- Door closer
Product features
- Adjustable closing force from EN2 to EN4.
- The arm system has 14 mm height adjustment and supports either handing.
- Closing speed, latching speed and backcheck adjust through front-facing valves.
- Maximum opening angle 180°; operating temperature −30 to +50°C.
Before ordering
Confirm door width, weight, handing and mounting space, and whether hold-open, coordinated closing or electrical release is required. Check the closer, rail, arm and mounting plate as a complete combination.
Fire or explosion-protection suitability requires verification against the current model, configuration and certificate scope; this page makes no blanket certification claim.
