ABLOY PRODUCT
Cover plate 023
023
Cover plate 023
023 is a cover plate with two holes.
- Brand
- ABLOY
- Model
- 023
- Type of product
- Escutcheon/rose/handle
Product features
- The overall dimensions are given as 65 × 140 × 1.5, without an explicit unit for that group.
- Hole diameter is specified as 40 mm; hole-position values are given as 32.5 and 107.5 without a reference datum.
Before ordering
Confirm the cylinder profile and single/double-sided operation, then measure door thickness, each cylinder-side length and fixings. A shared key platform does not establish dimensional interchangeability or compatibility with an existing master-key system.
Apart from the 40 mm hole diameter, dimension units and hole-position datums are unclear; confirm the complete installation dimensions before drilling.
Other products in this category
Compare the listed fields; these links do not imply interchangeability.
