ABLOY PRODUCT
Lock case EL755
EL755
Lock case EL755
EL755 is a Scandinavian motor lock for solid doors with comprehensive status indications, designed as an additional security lock alongside a day lock.
- Brand
- ABLOY
- Model
- EL755
- Mortise standard
- Scandinavian
- Installation type
- Mortise
- Locking Points
- Single point
Product features
- HiO connects components over CAN bus; the source requires an ARX system to provide the network.
- Mechanical opening by cylinder is always possible.
- The source supports use with door automatics.
- Has a day mode; in locked mode the lock locks automatically when the door closes.
- Can be electrically controlled by access or remote-control systems.
Before ordering
Provide the door type, handing, existing lock dimensions and access-control requirements. Check supply, control signals, power-loss operation and mechanical opening. Fire, escape or automatic-door applications require verification of the applicable doorset and supporting documents.
