ABLOY PRODUCT
Lock case LC4190
LC4190
Lock case LC4190
LC4190 is an automatically deadlocking lock with a forend snib controlling deadlocking and handle access.
- Brand
- ABLOY
- Model
- LC4190
- Mortise standard
- Finnish
- Installation type
- Mortise
- Locking Points
- Single point
Product features
- Upper position deadlocks on closing, opening by key or thumbturn only.
- Lower position also permits handle opening.
- Compatible striker plates: 4690, 4691, LP711, LP714, LP721, and LP731.
Before ordering
Check door thickness, handing, backset, faceplate and strike position before choosing the cylinder and handles. Similar numbers do not establish identical latch operation; verify exit or fire-door applications as a complete doorset.
Other products in this category
Compare the listed fields; these links do not imply interchangeability.
Request product documents
For data sheets, installation instructions or drawings, contact CLTECH with the model and required configuration.
Contact CLTECH for documents
