CY324T PROTEC2 Europrofile cylinder with thumbturn spindle
CY324T PROTEC2 Europrofile cylinder with thumbturn spindle
CY324T is a PROTEC2 Europrofile cylinder with a thumbturn spindle and a 31/31 mm basic length. Alongside its brass body and 11-disc mechanism, selection requires verification of the spindle interface to the chosen thumbturn.
- Profile
- Europrofile
- Inside configuration
- Thumbturn spindle
- Basic length
- 31/31 mm
- Material
- Brass
- Technology
- 11 discs
- Key platform
- ABLOY PROTEC2
Application
For projects coordinating the cylinder with a specified thumbturn or door trim. Supply the thumbturn, escutcheon and door dimensions to verify spindle-end shape, usable length and fixing method.
Selection limits
A thumbturn spindle is not universally compatible with every thumbturn. Do not order CY324T from a CY323T photograph alone. Confirm spindle dimensions and whether a thumbturn is included in the order.
How to choose
CY323T is described with a thumbturn; CY324T with a thumbturn spindle. This interface difference is central, and the shared 31/31 mm length does not justify unchecked substitution.
