ABLOY PRODUCT
CL110B SENTRY front-assembled steel-frame cam lock
CL110B SENTRY front-assembled steel-frame cam lock
CL110B is a metal-furniture lock that can be assembled from the front, with a steel frame and chrome finish. The key is removable only in the locked position, using the SENTRY platform for equipment cabinets, storage and workstations.
- Key platform
- ABLOY SENTRY
- Assembly
- Front assembly
- Frame material
- Steel
- Finish
- Chrome
- Key removal
- Locked position only
- Left-handed function
- Available; confirm configuration
Application
For metal furniture where front-assembly conditions need to be considered. The record also describes hardened steel components; assess the cabinet reinforcement, mounting hole and fixing method together.
Selection limits
The available product record does not give lock length; dimensions from CL100B or CL200B are not substituted. Front assembly does not mean no cabinet preparation is needed; obtain the matching installation dimensions.
How to choose
CL100B has a 37 mm brass body; CL110B centres on a steel frame and front assembly. Review CL201B for another steel-frame configuration, rather than substituting products solely because they share a key platform.
